1JT10-1

1JT10-1 Space & MIL-Spec Relay

  • This product is one of the 1/5 cubic inch series of relays, permanent magnet drive structure, its function, performance, dimensions, installation and terminal form conform to the requirements of the national military standard. Useful for aerospace, aerospace and ground equipment switching circuits and transmission signals.

1JT10-1 Small General-Purpose Relay

Environmental Characteristics

No. Parameter Environmental Specification
1 Quality Grade Ⓙ, G
II IV
2 Temperature Range (℃) -65~125
3 Relative Humidity (40±2) ℃, 92%~98%
4 Low Pressure (kPa) 0.67~0.27
5 Sinusoidal Vibration (Hz) 10~2000
(m/s2) 147 196
6 Shock (m/s2) 490 735
7 Constant Acceleration (m/s2) 490 735



Main Characteristics

Contact Arrangement SPDT Operating Time (ms) ≤5
Coil Power (W) 1.28 Release Time (ms) ≤5
Leak Rate (Pa.cm3/s) ≤1×10-2 Load Ratings Resistive 10A,28V d.c. (Resistive)
Contact Resistance(Ω) Initial ≤0.05 Low level 10μA~50μA, 10mV~50mV
After Life ≤0.1 Life Time (Cycles) 5×104
Insulation Resistance (MΩ) Normal ≥500 (500Vd.c.)
High Temp./Humidity ≥10 (500Vd.c.) Overload rating Resistive, 20A, 28V d.c.
Dielectric Strength (50Hz) Normal ≥500
Low pressure ≥200 Weight (g) ≤25



Electrical Specification

Specification No. Coil Voltage 25℃ Overall Temperature Range
Normal Max Coil resistance

(1±5%) Ω

Operating Voltage (max) Release Voltage (min) Operating Voltage (max) Release Voltage (min)
06 6 7.5 22 3.6 0.4 5.1 0.2
012 12 15 90 7.2 0.8 10.2 0.4
024 24 28 450 15.6 1.8 20.5 0.9
028 28 32 500 18 2 24 1



Dimensions

1jt10 1 Dimensions Mounting Style A 0 1jt10 1 Dimensions Mounting Style B 3 1jt10 1 Dimensions Mounting Style C 2
Mounting Style A(0) Mounting Style B(3) Mounting Style C(2)
Note: Vibration sensitive direction: Vertical



Circuit Diagram

Resistive Load Diagram

1jt10 1 Circuit Diagram 1jt10 1 Resistive Load Diagram



Order mark

  • G grade products:

Example: 1JT10-1/II28C

1JT10-1 / II 28 C
Product number Environmental rating Coil voltage Mounting style

Detailed specification: Q/RYJ0161-2000
