Specifications
| Characteristics |
Parameter |
| Quality Grade |
Military Products (Ⓙ) |
| Operating Temperature |
-30°C ~ 65°C |
| Vibration |
1 Hz ~16 Hz |
16 Hz ~ 60 Hz |
| Single-Sided Amplitude 1 mm |
10 m/s2 |
| Shock |
200 m/s2 |
| Water Pressure Test |
6.75 MPa |
| Salt Spray Test |
96 h |
| Mold Test |
28 d |
| Circuitry |
1 NO |
| Weight |
≤ 700 g |
| Connection Types |
YS9DH-0906ZJ10 receptacle |
| Pretravel |
5 mm ± 0.5 mm |
| Total Travel |
10 mm ± 0.5 mm |
| Life Underwater |
5000 cycles |
Electrical Ratings
| Contact Rating |
1 A, 31 Vd.c. |
| Contact Resistance
(not included cable) |
≤ 0.1 Ω |
| Insulation Resistance |
≥ 300 MΩ |
| Dielectric Withstanding Voltage |
500 Vr.m.s. |
Dimension
|
Circuit Diagram
|
 |
 |
Order Mark
| 1KX1-6S |
Ⓙ |
| Part Number |
Quality Grade |
Technical specification: RY3.604.145JT
