Specifications
| Characteristics |
Parameter |
| Quality Grade |
Military Products (Ⓙ / YC) |
| Operating Temperature |
-55°C ~ 85°C |
| Relative Humidity |
40°C ~ 42°C, 90% ~ 95% |
| Low Pressure Test |
0.67 kPa |
| High-frequency Vibration |
10 Hz ~ 2000 Hz |
| 150 m/s2 |
| Random Vibration |
10 Hz ~ 250 Hz |
250 Hz ~ 1000 Hz |
1000 Hz ~ 2000 Hz |
| +6 dB/Oct |
12 (m/s2)2/Hz |
-9 dB/Oct |
| Shock Response Spectrum |
15000 m/s2 |
| Acceleration |
490 m/s2 |
| Circuitry |
2 NC |
| Weight |
370 g/360 g |
| Connection Types |
Y27A-1410ZJB1H receptacle |
| Pretravel |
2.7 mm ~ 3.3 mm |
| Over travel |
≥ 4 mm |
| Total Travel |
7.3 mm ~ 7.9 mm |
| Total Travel Force |
58.5 N ~ 80 N |
| Electrical Life |
500 cycles |
Electrical Ratings
| Contact Rating |
27 Vd.c., 3 A |
| Contact Resistance |
≤ 0.075 Ω |
| Insulation Resistance |
≥ 1000 MΩ |
| Dielectric Withstanding Voltage |
≥ 1000 Vr.m.s. |
Dimension
|
Circuit Diagram
|
 |
 |
Order Mark
| 2KFM -2C/D |
YC |
| Part Number |
Quality Grade |
Technical Specification: Q/QJA20122/23-2021 (WS)
CASTPS04/004-2006
Q/RY20069-2007
