Specifications
| Characteristics |
Parameter |
| Quality Grade |
Military Products (Ⓙ) |
| Operating Temperature |
-55°C ~ 70°C, button local area high temperature resistance 400°C, 400 s |
| Relative Humidity |
30°C ~ 60°C, 95% |
| Random Vibration |
20 Hz ~ 181 Hz |
181 Hz ~ 1181 Hz |
1181 Hz ~ 2000 Hz |
| +3 dB/Oct |
21.62 (m/s2) 2/Hz |
-3 dB/Oct |
| Shock |
200 m/s2 |
| Acceleration |
195 m/s2 |
| Circuitry |
2 NC |
| Weight |
≤ 200 g |
| Connection Types |
J30JN-9ZK-A receptacle |
| Pretravel |
3 mm ± 0.5 mm |
| Total Travel |
15 mm ± 0.5 mm |
| Total Travel Force |
30 N ± 3 N |
| Life |
2500 cycles |
Electrical Ratings
| Contact Rating |
28 Vd.c., 5 A |
| Contact Resistance
(Including resistance of cable) |
≤ 0.15 Ω |
| Insulation Resistance |
≥ 300 MΩ |
| Dielectric Withstanding Voltage |
500 Vr.m.s. |
Dimension
|
Circuit Diagram
|
 |
 |
Order Mark
| 2KX-2P |
Ⓙ |
| Part Number |
Quality Grade |
Technical specification: RY3.604.128JT
