Specifications
| Characteristics |
Parameter |
| Quality Grade |
Military Products (Ⓙ) |
| Operating Temperature |
-45°C ~ 60°C |
| Relative Humidity |
(40 ± 2) °C, 95% |
| Random Vibration |
20 Hz ~ 114 Hz |
114 Hz ~ 274 Hz |
274 Hz ~ 1274 Hz |
1274 Hz ~ 2000 Hz |
| 0.5 (m/s2)2/Hz |
+3 dB/Oct |
1.2 (m/s2)2/Hz |
-3 dB/Oct |
| Shock |
147 m/s2 |
| Circuitry |
DPDT |
| Weight |
≤ 6 g |
| Connection Types |
Solder Strip |
| Total Travel |
3.6 mm ~ 4.0 mm |
| Total Travel Force |
≤15 N |
| Life |
2000 cycles |
Electrical Ratings
| Contact Rating |
27 Vd.c., 1 A |
| Contact Resistance |
≤ 0.1 Ω |
| Insulation Resistance |
≥ 20 MΩ |
| Dielectric Withstanding Voltage |
≥ 200 Vr.m.s. |
Dimension
|
Circuit Diagram
|
 |
 |
Order Mark
| 2KX-8 |
Ⓙ |
| Part Number |
Quality Grade |
Technical specification: RY3.604.028JT
