Specifications
| Characteristics |
Parameter |
| Quality Grade |
Military Products (Ⓙ) |
| Operating Temperature |
-55°C ~ 125°C |
| Low Pressure Test |
0.7 kPa |
| Sinusoidal Vibration |
5 Hz ~ 9 Hz |
9 Hz ~ 40 Hz |
40 Hz ~ 50 Hz |
| 30 m/s2 |
Single-Sided Amplitude 1.84 mm |
46 m/s2 |
| Random Vibration |
10 Hz ~ 100 Hz |
100 Hz ~ 1000 Hz |
1000 Hz ~ 2000 Hz |
| +6 dB/Oct |
6 (m/s2)2/Hz |
-6 dB/Oct |
| Shock |
500 m/s2 |
| Acceleration |
400 m/s2 |
| Circuitry |
2 NO |
| Weight |
≤ 220 g |
| Connection Types |
J30J-9ZKP plug |
| Pretravel |
1.6 mm ~ 2.1 mm |
| Total Travel |
≥ 8 mm |
| Total Travel Force |
≤ 70 N |
| Life |
1000 cycles |
Electrical Ratings
| Contact Rating |
28 Vd.c., 0.2 A, resistive |
| Contact Resistance |
≤ 0.01 Ω |
| Insulation Resistance |
≥ 500 MΩ |
| Dielectric Withstanding Voltage |
≥ 500 Vr.m.s. |
Dimension
|
Circuit Diagram
|
 |
 |
Order Mark
| 2KX0.2-1A |
Ⓙ |
| Part Number |
Quality Grade |
Technical Specification: Q/RY.J01224-2011
