2KX0.2-3 Travel Switch

2KX0.2-3 Travel Switch

The switch is suitable for axial-pressing surface-mounted application.
Excellent rain-proof performance, the switch is salt spray and mold resistant.
Applied to aerospace, aviation, weapons, and other military electronic devices.

Category: Travel Switch

Description

Specifications

Characteristics	Parameter
Quality Grade	Military Products (Ⓙ)
Operating Temperature	-55°C ~ 70°C
Relative Humidity	30°C ~ 60°C, relative humidity 95%
Random Vibration	20 Hz ~ 80 Hz	80 Hz ~ 350 Hz	350 Hz ~ 2000 Hz
	+3 dB/Oct	4 (m/s²)²/Hz	+3 dB/Oct
Shock	11500 m/s²
Acceleration	600 m/s²
Circuitry	2 NC
Weight	≤ 200 g
Connection Types	J70A222009261TH receptacle
Pretravel	6.5 mm ± 1.5 mm
Total Travel	11.5 mm ± 1 mm
Total Travel Force	≤ 35 N
Life	1000 cycles

Electrical Ratings

Contact Rating	28 Vd.c., 0.2 A
Contact Resistance	≤ 0.1 Ω
Insulation Resistance	≥ 5000 MΩ
Dielectric Withstanding Voltage	≥ 250 Vr.m.s.

Dimension	Circuit Diagram

Order Mark

2KX0.2-3	Ⓙ
Part Number	Quality Grade

Technical Specification: Q/RY.J01559-2023
