Specifications
| Characteristics |
Characteristics |
| Quality Grade |
Quality Grade |
| Operating Temperature |
-45°C ~ 70°C |
| Relative Humidity |
40℃ ± 2℃, relative humidity 95% ± 3% |
| Flight Vibration |
20 Hz ~ 300 Hz |
300 Hz ~ 1000 Hz |
1000 Hz ~ 2000 Hz |
| +3 dB/Oct |
4.5 (m/s2)2/Hz |
-6 dB/Oct |
| Shock |
400 m/s2 |
| Acceleration |
50 m/s2 |
| Circuitry |
2 NC |
| Weight |
95 g ± 15 g |
| Connection Types |
J30J-9ZKP receptacle |
| Differential Travel |
6.5 mm ± 0.4 mm |
| Total Travel |
9 mm ± 0.2 mm |
| Push-Button Reset Time |
≤ 10 ms |
| Overload (28Vd, 10A / 100ms) |
50 cycles |
| Electrical Life |
200 cycles |
Electrical Ratings
| Contact Rating |
28 Vd.c., 5 A |
| Contact Resistance |
≤ 0.1 Ω |
| Insulation Resistance |
≥ 100 MΩ |
| Dielectric Withstanding Voltage |
≥ 500 Vr.m.s. |
Dimension
|
Circuit Diagram
|
 |
 |
Order Mark
| 2KX5-4 |
Ⓙ |
| Part Number |
Quality Grade |
Technical specification: RY3.624.147JT
