Specifications
| Characteristics |
Parameter |
| Quality Grade |
Military Products（Ⓙ） |
| Operating Temperature |
-55°C ~ 70°C |
| Relative Humidity |
30°C ~ 60°C, 95% |
| Random Vibration |
20 Hz ~ 100 Hz |
100 Hz ~ 125 Hz |
125 Hz ~ 1125 Hz |
1125 Hz ~ 2000 Hz |
| 2 (m/s2) 2/Hz |
+3 dB/Oct |
2.5 (m/s2) 2/Hz |
-3 dB/Oct |
| Shock |
200 m/s2 |
| Acceleration |
204 m/s2 |
| Circuitry |
2 NC |
| Weight |
≤ 200 g |
| Connection Types |
J30J-9ZKP receptacle |
| Differential Travel |
≥15 mm |
| Total Travel |
21 mm ± 0.5 mm |
| Total Travel Force |
≥ 35 N |
| Life |
1000 cycles |
Electrical Ratings
| Contact Rating |
3 A, 28 Vd.c. |
| Contact Resistance |
≤ 0.15 Ω |
| Insulation Resistance |
≥ 300 MΩ |
| Dielectric Withstanding Voltage |
500 Vr.m.s. |
Dimension
|
Circuit Diagram
|
 |
 |
Order Mark
| 2KX6-1 |
Ⓙ |
| Part Number |
Quality Grade |
Technical specification: RY3.604.080JT
