Specifications
| Characteristics |
Parameter |
| Quality Grade |
Military Products (Ⓙ) |
| Operating Temperature |
-55°C ~ 85°C |
| Relative Humidity |
(40 ± 5) °C, 98% |
| Low Pressure Test |
12000 kPa |
| Sinusoidal Vibration |
10 Hz ~ 2000 Hz |
| 196 m/s2 |
| Shock |
196 m/s2 |
| Acceleration |
176 m/s2 |
| Circuitry |
4 From c |
| Weight |
≤ 400 g |
| Connection Types |
JY27496E11B35PN receptacle |
| Pretravel |
5 mm ± 0.5 mm |
| Overtravel |
≥ 14 mm |
| Pretravel Force |
≤ 50 N |
| Total Travel Force |
60 N ~ 100 N |
| Life |
20000 cycles |
Electrical Ratings
| Contact Rating |
28 Vd.c., 5 A |
| Contact Resistance |
≤ 0.05 Ω |
| Insulation Resistance |
≥ 1000 MΩ |
| Dielectric Withstanding Voltage |
≥ 500 Vr.m.s. |
Dimension
|
Circuit Diagram
|
 |
 |
Order Mark
| AK-45A |
Ⓙ |
| Part Number |
Quality Grade |
Technical specification: RY3.604.125JT
