Specifications
| Characteristics |
Parameter |
| Quality Grade |
Military Products (Ⓙ) |
| Operating Temperature |
-55°C ~ 85°C |
| Relative Humidity |
(40 ± 5) °C, 98% |
| Low Pressure Test |
0.67 kPa |
| Random Vibration |
10 Hz ~ 163 Hz |
163 Hz ~ 300 Hz |
300 Hz ~ 1000 Hz |
1000 Hz ~ 2000 Hz |
| 8 (m/s2)2/Hz |
+4 dB/Oct |
18 (m/s2)2/Hz |
-6 dB/Oct |
| Shock |
500 m/s2 |
| Acceleration |
500 m/s2 |
| Circuitry |
4 From c |
| Weight |
≤ 200 g |
| Connection Types |
XK18J12Z receptacle |
| Pretravel |
2 mm ~ 3.5mm |
| Total Travel |
≥ 7.5 mm |
| Asynchronous between Groups when Releasing |
≤ 0.3 mm |
| Pretravel Force |
≤ 37 N |
| Total Travel Force |
≤ 88 N |
| Life |
2000 cycles |
Electrical Ratings
| Contact Rating |
30 Vd.c., 5 A |
| Contact Resistance |
≤ 0.05 Ω |
| Insulation Resistance |
≥ 300 MΩ |
| Dielectric Withstanding Voltage |
≥ 500 Vr.m.s. |
Dimension
|
Circuit Diagram
|
 |
 |
Order Mark
| MK-4BA |
Ⓙ |
| Part Number |
Quality Grade |
Technical specification: RY3.604.101JT
