Specifications
| Characteristics |
Parameter |
| Quality Grade |
Military Products (Ⓙ) |
| Operating Temperature |
-55°C ~ 125°C (400°C, 100 s) |
| Relative Humidity |
60 V, relative humidity 95% |
| Random Vibration |
20 Hz ~ 355 Hz |
355 Hz ~ 710 Hz |
710 Hz ~ 1400 Hz |
1400 Hz ~ 2000 Hz |
| 4 (m/s2)2/Hz |
11 (m/s2)2/Hz |
16 (m/s2)2/Hz |
10 (m/s2)2/Hz |
| Shock |
5200 m/s2 |
| Acceleration |
165 m/s2 |
| Rain Test |
40 min |
| Circuitry |
1 NO, 2 NC |
| Weight |
≤ 500 g |
| Connection Types |
JY27496E09F35PA receptacle |
| Total Travel |
7.5 mm ~ 8.0 mm |
| Total Travel Force |
≤ 100 N |
| Life |
2000 cycles |
Electrical Ratings
| Contact Rating |
28.5 Vd.c., 5 A |
| Contact Resistance |
≤ 0.1 Ω |
| Insulation Resistance |
≥ 300 MΩ |
| Dielectric Withstanding Voltage |
≥ 500 Vr.m.s. |
Dimension
|
Circuit Diagram
|
 |
 |
Order Mark
| MK-4D |
Ⓙ |
| Part Number |
Quality Grade |
Technical specification: RY3.604.040JT
