JGW-3023A Optical-MOS Relay

  1. Dual Bidirectional configuration
  2. SPDT
  3. Ceramic housing DIP/SMD package
  4. Input and output photovoltaic isolation
  5. Wide input voltage and input current range
  6. Fast switching speed
  7. Environmental adaptability
  8. High reliability
  9. Standard: Q/RY.J01159.19—2011
Category:

Description

JGW-3023A Optical-MOS Relay

Standard

Q/RY.J01159.19—2011



Application

Suitable for defense, scientific research, industrial control and modern management, such as isolated drive for aerospace, aviation and terrestrial electronic equipment, coupled amplification of digital signals, switching of analog signals, power transistor drive, measuring instruments, etc. Suitable for harsh environments



Technical Parameters Min. Typ. Max. Unit
Input Parameters
Rated input current 10 mAd.c.
Input current range 5 25 mAd.c.
Input switching current 5.0 mAd.c.
Input shutdown voltage 0.8 Vd.c.
On time 1.5 ms
Shutdown time 0.4 ms
Output parameters
Output configuration Bidirectional
Number of output circuit groups 1H, 1D (SPDT)
Output port N.O. N.C.
Rated output current ±0.3 Ad.c.
Rated output voltage ±50 Vd.c.
Output on-resistance ≤2.0 ≤2.5
Output leakage current ≤1.0 μA
Transient voltage ±60 Vd.c
Electrical insulation parameters
Insulation resistance 1000
Dielectric withstand voltage 1000 Vr.m.s.
Power consumption 0.8 W
Environmental parameters
Seal leak rate 5×10-3 Pa·cm3/s
Random vibration 40
10~2000
(m/s2)2/Hz, Hz
High Frequency Vibration 294, 10~3000 m/s2, Hz
Constant acceleration 49000 m/s2
Shock 14700, 0.5 m/s2, ms
Storage temperature -55~125
Operating temperature -55~105
Other parameters
Weight 1.5 g
Dimensions 10.16×7.6×3.8 mm



JGW 3023A Fig. 1 Turn On time vs. Output Voltage - JGW-3023A Optical-MOS Relay JGW 3023A Fig. 2 Output Current vs. Temperature curve - JGW-3023A Optical-MOS Relay JGW 3023A Fig. 3 Inrush Current vs. Inrush Current duration curve - JGW-3023A Optical-MOS Relay
Fig. 1: Turn-On time vs. Output Voltage Fig. 2: Output Current vs. Temperature curve Fig. 3: Inrush Current vs. Inrush Current duration curve
JGW 3023A Fig. 4 On time vs. Input Current curve - JGW-3023A Optical-MOS Relay JGW 3023A Fig. 5 Input Current vs. Input Voltage curve - JGW-3023A Optical-MOS Relay JGW 3023A Fig. 6 Output leakage current vs. Temperature curve - JGW-3023A Optical-MOS Relay
Fig. 4: On time vs. Input Current curve Fig. 5: Input Current vs. Input Voltage curve Fig. 6: Output leakage current vs. Temperature curve





Drawing
JGW 3023A Drawing - JGW-3023A Optical-MOS Relay
Internal circuit diagram Overhead wiring diagram
JGW 3023A Internal circuit diagram - JGW-3023A Optical-MOS Relay JGW 3023A Overhead wiring diagram - JGW-3023A Optical-MOS Relay



Order Mark

Example: JGW3023A Y

JG W 3023A Y
Solid relay main name Shape symbol (W, C or X) Design Number Screening level

Note: The screening level (Y or W) and DIP/SMD should be indicated.
