SD301 Single-axis Fiber Optic Gyroscope

The product has the characteristics of small size, low power, large measuring range and good linearity. It is a typical all-digital closed-loop fiber optic gyroscope single machine; it greatly reduces the interferometric closed-loop fiber through the miniaturization of optical circuit components and the improvement of assembly process. The volume of the gyro; the realization of this product is of great significance for promoting the miniaturization and intelligence of the inertial weapon system.

Categories: ,

Description

SD301 Single-Axis Fiber Optic Gyroscope

Application Field

This product has the characteristics of small size, low power consumption and large measurement range, and can be widely used in the field of on-board automatic driving system.



Main Technical Specifications

Parameter Technical specifications Remarks
Zero offset stability ≤3°/h 1σ,10s smooth
Scale factor nonlinearity ≤50 ppm 0.01~1000°/s
Measuring range ±3000°/s
Zero deviation in the vibration ≤10°/h 6.06g
Full temperature zero bias stability ≤20°/h 1σ, 10s smooth
Start Time ≤1 s
Product size Ф24.2mm×49.5mm Interface pins not included
49.7mm×26.2mm×26.2mm
Product Weight ≤40 g Round cross section
≤60 g Square cross section
Maximum power consumption ≤1.5 W
Operating temperature -40 ℃ ~ 70℃
Electrical Interface RS422 Can be customized according to user requirements
Power supply requirements 5V±0.5V
Installation method Base level fastening or clamping Can be customized according to user requirements



Mechanical Drawings

SD301 Mechanical Drawings - SD301 Single-axis Fiber Optic Gyroscope
