AK-50 Series Specifications |
||
| P/N | AK-50 | AK-50B |
| Electrical Rating Resistive | Rated voltage: 28VDC
Rated Current: 3A |
Rated voltage: 28VDC
Rated Current: 3A |
| Pre-travel PT (mm) | 0.5～1.5 | 0.5～1.5 |
| Over travel OT (mm) | ≥2.5 | ≥2.5 |
| Differential Travel DT (mm) | ≤0.5 | ≤0.5 |
| Operating Force OF(N) | 14.7～49 | 14.7～49 |
| Releasing Force RF(N) | ≥15 | ≥15 |
| Total TravelT TP(mm) | ≤98 | ≤98 |
| Operating Temp (℃) | -55～85 | -55～85 |
| Weight (g) | ≤260 | ≤260 |
| Mechanical Life (cycles) | 15000 | 15000 |
| Insulation Resistance (normal) MΩ | ≥1000 | ≥1000 |
| Insulation Resistance (damp heat) MΩ | ≥10 | ≥10 |
| Dielectric Withstand Voltage (normal) V ac | 500 | 500 |
| Salt fog (h) | 48 | 48 |
AK-50
AK-50 Aviation & Military Push Button Switch
1. Large load capacity;
2. With instantaneous action function, the action is sensitive and the parameter accuracy is high;
3. The minimum Differential Travel range is 0.5mm max;
4. Electric life reaches 15000 times.
Standard: Meet GJB150-86 military equipment environmental test method (part), GJB360A-96 electronic and electrical component test method (part), GJB809A-97 micro switch general technical specification (part), AK-50 technical specification, AK-50B Product specification (internal).
