Electrical characteristics
| Item | Parameters | Item | Parameters |
| Current | 1A (high frequency) | Current | 3A (low frequency) |
| Withstand Dielectric Voltage | 800V (50Hz.r.m.s.) | Insulation resistance | 5000 MΩ (500V DC Test voltage) |
| Voltage | 220V | Contact resistance (low frequency) | ≤10MΩ |
| Frequency range (high frequency) | 0~1GHz (With flexible cable) | High frequency point characteristic impedance | 50Ω |
| Contact resistance of outer conductor (high frequency) | ≤7MΩ | Central conductor contact resistance (high frequency) | ≤55MΩ |
| Insertion loss | ≤0.3dB (within the frequency range of 1MHz~100MHz) | Voltage standing wave ratio | ≤1.3 (within the frequency range of 1MHz~100MHz) |
Environmental characteristics
| Item | Parameters | Item | Parameters |
| Operating temperature | -55°C ~+125°C | Random vibration | 0. 4G2/Hz, 23. 1G |
| vibration | 10 ~2000Hz, 147m/s2 | Shock | 735 m/s2, 11ms |
| Salt spray | 96h | Temperature shock | -55°C ~+125°C |
| Mechanical life | 500 times |
Order mark
Example: J30J-15TJ6GAP
|
J30J |
15 | TJ | 6 | GA | P | |
| Main code | Number of low-frequency contacts: 15, 21 | Types of connectors and low-frequency contacts:
|
Low-frequency contact end type:
|
Number of high-frequency contacts: 5, 6 | High-frequency contact outlet:
|
High frequency contact category:
|
Dimensions
 |
 |
| J30J-15TJ6GAP | J30J-15ZK6GAS |
 |
 |
| J30J-21TJ5GAP | J30J-21ZK5GAS |
 |
 |
| J30J-21TJN5GP | J30J-21ZK5GS |
Mounting board hole size drawing
 |
 |
| J30J-15TJ6GAP/ZK6GAS | J30J-21TJ5GAP/ZK5G(A)S |
